The Essex incorporates the latest design and engineering enhancements from Steinway’s dedicated research and development team. By utilizing specially engineered materials, large-scale production techniques, and carefully selected manufacturing environments, the Essex is able to deliver a level of musical performance previously unattainable in its price range.

Essex uprights come in a variety of case styles, and are well-suited for the spectrum of home décor styles and personal aesthetics. From satin black to aubergine mahagony; brass hardware to nickel; contemporary to classic — the Essex line celebrates the marriage of form and function.

High-grade, straight-grained, quarter-sawn spruce is selected for its resonant qualities and high strength-to-mass ratio. The soundboard is solid and not laminated, which creates the best resonance and projection of sound. In 1936, Steinway patented the diaphragmatic soundboard, which is thicker in the middle and gently tapered to the edges. The Essex soundboard is tapered from bass to treble resulting in a stronger, richer, fuller tone.

Essex backposts are massive — providing a solid foundation for the resonating soundboard and tensioned vibrating strings, thus helping create a beautiful tone. Essex backpost locations are staggered — located where the string tension is greatest, instead of neatly equidistant. Massive staggered backposts help provide superb tone and maximum stability, ensuring the piano will last, tunings will be more stable, and piano tone will be enhanced for the years and decades to come.

A low tension string scale, designed by Steinway, gives a fuller, richer, warmer tone by allowing more of the lower partials to sing. It also has more sustain, is more powerful, has more dynamic range, and provides warmer and more mellow tones.

All-wood action parts, solid spruce keys, and excellent action geometry work seamlessly together to move the hammers to the strings and to create an excellent action touch. The beautiful tone produced by the Steinway–specified Essex hammers actually enhances the action touch by “giving back” to the player a beautiful tone.

Dimensions

Height: 123 cm (48½”)
Width: 151 cm – 152 cm (59½” – 59¾”)
Depth: 67 cm (26½”)
Net Weight: 255 kg (561 lb)



Encasement

Furniture
Classic studio and school-style cases designed by Steinway & Sons. Furniture Cases designed by William Faber.

Finish
Sapele Mahogany Satin, and Walnut Satin

Hardware
Brass

Technical Specifications

Backframe/Posts
Staggered spruce backposts (5). Total CSA: 500 cm² (77.5 in²). Thickness of post: 10 cm. Width of post: 10 cm.

Pinblock
Laminated multi-directional maple. Thickness: 35 mm.

Soundboard
Solid spruce. Linear taper. Vibrating area: 1.26 m² (1,948 in²)

Ribs
Ribs notched into inner rim (no floating ribs). Ribs made of spruce and staggered/graduated. Number of ribs: 11

Bridges
Vertically laminated maple base with solid maple cap.

Scale
Designed by Steinway. 16,695 kg (36,730 lb) tension.

Plate
Cast iron, painted with Steinway Gold.

Tuning Pins

Carbon steel, nickel coating.

Strings
Roslau wire. Number of sizes of treble strings: 14. Lowest tenor note: 27. Number 1 speaking length: 114 cm (44.9″)

Hammers
Specified by Steinway. Weight of topfelt: 7 kg (15 lb).

Action
All wood (no plastic) for all moving parts. Aluminum action rails.

Keys
Steinway design. Spruce.

Keybed
Lauan, Maple, Spruce.

Pedals
Brass. Middle pedal on EUP-123S is Bass Sustain. Middle pedal on all other models is for muffler.

Features
All wood Back construction (no MDF except in cabinet parts). Solid filler blocks in backframe (near top). Backposts are large and staggered. Bench: Matching cushioned bench.

Casters
Double-rubber casters on EUP-123S. Brass casters on all other EUP-123 models.
